version: 1.2.0

Avalon(A) allows you to easily add 3d to a set of html elements to simulate a deepness effect. To make this 3d effect noticeable, all html elements pertaining to the transformed layer (basically the root container to which the 3d effect get applied to) - rotate on their x and y axis according to mouse movements.

Summary

Dependencies

Example

Html

<div id="frame-3d"> <!-- 3d Frame -->
    <div id="avalona-inner-frame"> <!-- transformed layer -->
        <div id="half-circle" data-avalonA-transform="ox: 0.5; oy: 0.35; z:-300"></div>
            <div id="square" data-avalonA-transform="z:75; rx:20.32; ry:5; rz:-10.2">
                <div id="inner-square" data-avalonA-transform="z:150"></div>
            </div>
        <div id="circle" data-avalonA-transform="x:100; y:150; z:200;rx:45"></div>
    </div>
</div>

It is mandatory to have at least the 3d Frame and transformed layer defined when Avalon(A) initialization occurs. Within the 3d Frame, the element div having the id avalona-inner-frame becomes the transformed layer.

data-avalonA-transform attribute value has the following structure:

x: x translation; y: y translation; z: z translation; rx: x rotation; ry: y rotation; rz: z rotation; ox: x origin transform; oy: y origin transform; oz: z origin transform

All properties are optional.

Script

$(function(){
    AvalonA('frame-3d', 'avalona-inner-frame').start();
});

API

Constructor options

It is possible to pass an object along with the id of the 3d Frame to set options:

$(function(){
    AvalonA('frame-3d', 'avalona-inner-frame', {option: value}).start();
});
tAttr

Changes the name of the attribute used to define layer transformations. Default value is data-avalonA-transform.

fy

A function that affects the amount of rotation triggered by the mouse movements on the y axis.

AvalonA('frame-3d', 'avalona-inner-frame', {fy: function(rotation){
    return rotation * 2;
} }).start();

Default function as no effect on the rotation value.

fx

A function that affects the amount of rotation triggered by the mouse movements on the x axis. Default function as no effect on the rotation value.

activeArea

When available, restrict mouse movements tracking to this area: moving outside the area reset the transformed layer rotation.

var options = {
    activeArea: {
        position: {
            x: 'auto',
            y: '15%'
        },
        attachment: 'scroll',
        width: '150px',
        height: 100
    }
};
AvalonA('frame-3d', 'avalona-inner-frame', options).start();

Enable the debug option to display the area ( for development purpose only ).

activeArea.width
activeArea.height
[activeArea.position]

Set the position of the area. Possible values:

[activeArea.attachment]

Act like css position: absolute|fixed. Possible values:

animation

Animates the transformed layer when mouse is outside the active area – meaning the actual activeArea or simply the 3d Frame when no activeArea is provided. The animation plays as well when the mouse is iddle.

The animation object must have the following api:

animation: {
    play: function(transformedLayer){
        // animation code goes here
    },

    pause: function(){
        // pause code goes here
    }
}

As the example shows, the play() method received as first argument the transformed layer, thus one can animate any attribute of this element – not just the rotation.

idleTimeout

The delay, in milliseconds, after which the user is considered idle when there is no mouse movements:

When the user is idle, the animation resumes – if any – and endrotation event is triggered.

debug

Enable debug logs and display when set to true.

Methods

refresh()

Fetch 3d Frame and transformed layer from the DOM and apply initial setup.

Return layers (see layers property).

enable()

Set disabled flag to false and call refresh().

start()

Alias for enable().

disable()

Flatten transformed layer, remove mouse movement tracking, unable events and pause animation.

refreshTransform( [target : selector OR html node] )

Update transformations according to new values of data-avalonA-transform. When target is provided, only first matching html node get updated.

freeze()

Stop animation – if any – and disable events if Avalon(A) is “enabled”.

release()

Resume animation – if any – and enable events if Avalon(A) is “enabled”.

Properties

layers

Provides all nodes picked up while running start() or refresh() or enable() method. It has the following structure:

{
    "#<layer-id-1>": <Layer>,
    "#<layer-id-2>": <Layer>,
    ...
    ".<layer-class-1>": <Layer>[],
    ".<layer-class-2>": <Layer>[],
    ...
    all: <Layer>[]
}

The layers property references all transformed html elements by their ids (#layer-id), their css classes (.layer-class) and all elements are also referenced under all, including those not having neither id nor class attribute.

Each html element is wrapped by a Layer object — private to the lib, meaning you can’t directly instanciate one — so that it is more convenient to manipulate transform properties.

The Layer instance has the following properties:

The node style get updated – according to the x, y, z, … getter/setter – only after calling either refreshTransform method (see refreshTransform()) or <Layer>.refresh(). Calling refreshTransform with no node argument also update the layers property: so if transformations has been added to a new node, this one will also end up as a Layer in the layers field.

The Layer instance has the following methods:

Events

It is possible to add event listeners like this

var options = {
    on: {
        event: function(){ /* event code goes here */ },
    }
};
AvalonA('frame-3d', 'avalona-inner-frame', options).start();

or this

var a = AvalonA('frame-3d', 'avalona-inner-frame', options);
a.onevent = function(){ /* event code goes here */ };
a.start();

Available events:

startrotation

Triggered when transformed layer rotation starts.

endrotation

Triggered when transformed layer rotation ends.

ready

Triggered ONLY ONCE by start() or enable() BEFORE transformations gets actually applied.

refresh

Triggered every time by refresh() or refreshTransform() AFTER transformations has been applied.

enable

Triggered every time Avalon(A) gets “enabled” – by enable() – AFTER transformations has been applied.

If Avalon(A) was already “enabled” by the time enable() gets called, the event is not triggered again.

start

Alias for enable event.

AvalonAnimation

Provides a collection of preset animations.

Balance

Adds a balancing movement between two rotation angles.

Dependencies

Note that the TweenMax module includes the TweenLite one – see GSAP documentation for details.

Examples

Example 1

animation: AvalonAnimation.Balance()

Example 2

animation: AvalonAnimation.Balance({
  duration: 0.75,

  from:{
    rx: 30,
    ry: -30
  },

  to:{
    rx: -90,
    ry: 30
  }
})
Options

Spotlight

Rotates like a spotlight.

Dependencies

Note that the TweenMax module includes the TweenLite and BezierPlugin ones – see GSAP documentation for details.

Examples

Example 1

animation: AvalonAnimation.Spotlight()

Example 2

animation: AvalonAnimation.Spotlight({
  duration: 5,
  direction: 'ccw',
  angle: 10
})
Options

Atom

Rotates a layer or a group of layers like electrons around an atom’s nucleus.

Dependencies
Example
animation: AvalonAnimation.Atom({
  duration: 20,
  selector: '.electron',
  axis: ['y','z']
})
Options

(*) non-transformed means not having the data-avalonA-transform attribute (or the one define through “tAttr” option).

SpeedTester utility

The SpeedTester (SpeedTester.min.js) allows you to check system performance before activating Avalon(A), thus preventing to undermine the usability of your website. It is meant to be used like this:

Main html document – preferably before loading any other scripts

<script>
    var speedTester = new SpeedTester(< how many times the test must be run (default 1) >);
    speedTester.run();
</script>

Main script – after document as been loaded

speedTester.oncomplete(function(results){
    if(results.fps > 30){
        AvalonA('frame-3d', 'avalona-inner-frame').start();
    }else{
        console.warn('Your frame rate is too low, recommended: 30');
    }
});

Browser compatibility

Nothing happens on browsers that doesn’t support 3d transform.

Using it with require.js

Avalon(A) is AMD compliant: if require.js is present, AvalonA function won’t be exposed as a global variable but as a module having the same name. The same goes for AvalonAnimation plugin and SpeedTester utility.

As an AMD module, AvalonA requires tweenlite module. AvalonAnimation requires tweenmax,tweenlite and GSEasesmodules, where GSEases contains key/value pairs of standard greensock easing functions — the ones bundled with TweenMax.

GreenSock specifics

Keep in mind that since GreenSock bundles several modules within one file — indeed TweenMax file contains TweenMax as well as TweenLite, CSSPlugin, BezierPlugin, Eeasin, etc — it needs special care to be used with require.js.

Check out this code sample to understand how to use Avalon(A) and GreenSock with require.js.
